ADX-1881 HD/SD 8 AES Disembedder
Guide to Installation and Operation
ADX-1881 Page 5 of 12
AES OUTPUT AES OUT 1-2 [ GROUP 1, GROUP 2, GROUP 3, GROUP 4 ]
AES OUT 3-4 [ GROUP 1, GROUP 2, GROUP 3, GROUP 4 ]
AES OUT 5-6 [ GROUP 1, GROUP 2, GROUP 3, GROUP 4 ]
AES OUT 7-8 [ GROUP 1, GROUP 2, GROUP 3, GROUP 4 ]
AES OUT 1 LEVEL LEFT [MUTE, -95.5 dB, ..., 0 dB, ..., 12dB]
RIGHT [MUTE, -95.5 dB, ..., 0 dB, ..., 12dB]
LOCK [ OFF, ON ]
PHASE INVERT LEFT [ OFF, ON ]
RIGHT [ OFF, ON ]
MUTE L&R [ OFF, ON ]
SWAP L&R [ OFF, ON ]
AES OUT 2 Same as AES OUT 1
AES OUT 3 Same as AES OUT 1
AES OUT 4 Same as AES OUT 1
AES OUT 5 Same as AES OUT 1
AES OUT 6 Same as AES OUT 1
AES OUT 7 Same as AES OUT 1
AES OUT 8 Same as AES OUT 1
AES DELAY
[ NONE, 0.5 FRAME, 1.0 FRAME, 1.5 FRAME,
2.0 FRAME, 2.5 FRAME, 3.0 FRAME ] Half values are not relevant
for progressive format
LTC OUTPUT FROM [ FIRST ATC, SECOND ATC ] Only for HD Input
[ AUTO, 10, 11, …, 20 ], in 525
DVITC LINE
[ AUTO, 7, 8, …, 22 ], in 625
Only for SD Input
DELAY [ NONE, 1 FRAME, 2 FRAME, 3 FRAME ]
RS-422
OUTPUT
MODE [ SERIAL, METADATA ]
METADATA LINE [ LINE 9, LINE10, …, LINE20 ]
(continued)
