Grass Valley ADX-1881 - Manual (Page 4)

ADX-1881 HD/SD 8 AES Disembedder
Guide to Installation and Operation
Page 4 of 12 ADX-1881
ADX-1881 Menus
STATUS
NO REAR/ NO SIGNAL/ 720p50/ 720p60/ 720p59.94/ 1080p24/ 1080p24sF/ 1080p23.98/
1080p23.98sF/ 1080p25/ 1080i50/ 1080p29.97/ 1080i59.94/ 625/ 525
AUDIO GROUPS NONE / 1234
EMBEDDED TC NONE / PRESENT
EMBEDDED
RS422
NONE / PRESENT
EMBEDDED GPI NONE / 12
AES OUT 1 BITS 16 BIT / 20 BIT / 24 BIT / OTHER
MODE N.I. / 2 CHANNEL / 1 CHANNEL / P/S / STEREO
EMPHASIS N.I. / NONE / 50/15-us / J.17
USE CONSUMER / PROFESSIONAL
ENCODING LINEAR PCM / NON PCM
AES OUT 2 Same as AES OUT 1
AES OUT 3 Same as AES OUT 1
AES OUT 4 Same as AES OUT 1
AES OUT 5 Same as AES OUT 1
AES OUT 6 Same as AES OUT 1
AES OUT 7 Same as AES OUT 1
AES OUT 8 Same as AES OUT 1
USER PRESET LOAD [ USER 1, USER 2, USER 3, USER 4, USER 5 ]
SAVE [ USER 1, USER 2, USER 3, USER 4, USER 5 ]
(continued)
