8
5.2 Hardware specifications
Video reference signal output
Output connectors
BNC x 9
OUT1-3(LineA)
OUT4-6(LineB)
OUT7-9(LineC)
* SD/HD setting can be specified per LINE group.
Format
1920 x 1080 p/PsF 23.98/24/25/29.97/30
1920 x 1080 i 50/59.94/60
1280 x 720 p 23.98/24/25/29.97/30/
50/59.94/60
720 x 480 i 59.94
720 x 576 i 50
HD-Sync Tri-level
SD-Sync
Black burst
* Can be switched to test pattern.
* Compliant to SMPTE318M-B in NTSC mode.
Video/audio clock
accuracy
+-4.0ppm
* For all operation temperature
VSYNC output delay
between HD and SD output
None
* For both REF sync and Internal sync.
Reference input
Reference input connector BNC x 1
* For both SD/HD
Format See page 11 for details.
VSYNC output delay from
locked reference input
None
Delay adjustment Not supported
Burst clock lock Not supported
SMPTE318M lock Not supported
