18
8964DEC/-FS Instruction Manual
Configuration
provides a complete summary of the 8964DEC processing functions
and a comparison of the functionality available with each control type
along with the ranges and default values for each parameter. The table is
organized to provide a breakdown of the video path processing adjust-
ments by specific grouping of line type in the video signal.
Table 5. Summary of 8964DEC Configuration Functions By Line Type
Processing
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Rotary
Switch
Bank/Setting
Control
Panel
Mnemonic
Notes/
Conditions
All Lines, Channels 1–4. Composite In Video Path Processing (before decoding).
AGC (Auto Gain Control)
Off
On/Off
Video Composite In/
Enable AGC checkbox
1:3
N/A
On enables AGC
ACC (Auto Chroma Control)
Off
On/Off
Video Composite In/
Enable ACC checkbox
2:9
N/A
On enable ACC
Input Video Gain
100%
72.5–200%
(0.5% steps)
Video Composite In/
Input Video Gain (%)
1:4
vciGain1-4
AGC off.
Input Chroma Gain
100%
50–200%
(0.6% steps)
Video Composite In/
Input Chroma Gain (%)
1:5
vciChGn1-4
ACC off.
Detail Enhancer
Disable
Disable, Low,
Medium or High
Picture Enhancer/
Select Disable, Low, Medium
or High radio button
3:B (Disable
or Low)
3:C (Medium
or high)
N/A
8964DEC and
8964DEC-FS
Active Picture Lines, Video Path Processing, Channels 1–4. All settings Global (affects all active picture lines).
Saturation/Chroma Gain
100%
50–200%
(0.6% steps)
1
Video Proc/
Saturation/Chroma Gain (%)
1:8
ChrGain1-4
Active only when
Video Proc is
enabled.
Hue/Chroma Phase
0
± 180 degrees
(1.4 degree steps)
1
Video Proc/
Hue/Chroma Phase (deg)
1:9
ChrmPhs1-4
Brightness/Y Offset
0
± 400 mV
(3 mV steps)
1
Video Proc/
Brightness/Y Offset (mV)
1:7
YOffset1-4
Contrast/Y Gain
100%
50–200%
(0.6% steps)
1
Video Proc/
Contrast/Y Gain (%)
1:6
YGain1-4
Remove setup from active
video
Yes
Yes/No
Video Composite In/
Remove setup from active
video checkbox
1:2
N/A
525 only.
TSG (Test Signal Generator)
(100% Color Bars)
Off
On/Off
Video Proc/
Color Bars 100% checkbox
1:D
(enable mode)
1:E
(choose type)
TstSig1-4
Test signals are not
adjustable.
TSG (Test Signal Generator)
(Pathological)
Off
On/Off
Video Proc/
Pathological Test checkbox
OSD (On Screen Display)
Off
On/Off
OSD Control/
On Screen Display
1:1
N/A
Jumper JP2 must be
enabled on module.
Decode Mode
Comb
Adaptive
Adaptive/Notch
Video Composite In/
comb adaptive,
comb non-adaptive, or notch
1:A
(enable mode)
1:B
(choose type)
N/A
Chroma Kill
Off
On/Off
Video Proc/
Chroma Kill checkbox
1:C
N/A
Global, also affects
CVBI lines.
Monochrome In
Off
On/Off
Video Composite In/
Monochrome In checkbox
2:A
N/A
On indicates mono-
chrome input signal.
Insert EDH
On
On/Off
Functional View/
Insert EDH checkbox
N/A
N/A
Remote control only.
