18 electrolux
Fitting the Hob into the Worktop
Before fitting the hob into the cut out, an
adhesive seal must be fitted to the underside
outside edge of the hob. It is essential that no
gaps are left in this seal in order to prevent
spillage near the hob seeping into the cabinet
below.
1) Remove the pan supports, the burners
caps and crowns and turn the hob
upside down, taking care the ignition
candles are not damaged in this
operation.
2) Place the sealing gasket (C) all around
the glass top edge as shown in diagram
A.
3) Place the hob in the cut out,
taking care of its centring.
4) Fit the hob in the cut out and push it
down until the glass top and the working
top make contact, as shown in diagram
B.
C C C C C
C) Sealing gasket
A
B
