electrolux 13
OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS Width: 590 mm
Depth: 520 mm
CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS Width: 560 mm
Depth: 480 mm
SUPPL SUPPL SUPPL SUPPL SUPPLY CONNECTIONS Y CONNECTIONS Y CONNECTIONS Y CONNECTIONS Y CONNECTIONS
G a s : G a s : G a s : G a s : G a s :
R 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
Electric: Electric: Electric: Electric:
230 V
~ 50 Hz supply, 3 core flexible cable with non rewireable plug
fitted with a 3 amp cartridge fuse.
HEA HEA HEA HEA HEAT INPUT T INPUT T INPUT T INPUT T INPUT
Rear Right Burner Rear Right Burner Rear Right Burner Rear Right Burner Rear Right Burner 1.9 kW (6485 BTU/HR)
(semi-rapid) (semi-rapid) (semi-rapid) (semi-rapid) (semi-rapid)
Front Right Burner Front Right Burner Front Right Burner Front Right Burner Front Right Burner 1.9 kW (6485 BTU/HR)
(semi-rapid) (semi-rapid) (semi-rapid) (semi-rapid) (semi-rapid)
Rear Left Burner Rear Left Burner Rear Left Burner Rear Left Burner Rear Left Burner 2.9 kW Natural Gas (9898 BTU/HR)
(rapid) (rapid) (rapid) (rapid) (rapid) 2.7 kW L.P.G.
Front Left Burner Front Left Burner Front Left Burner Front Left Burner Front Left Burner 1.0 kW (3413 BTU/HR)
(auxiliary) (auxiliary) (auxiliary) (auxiliary) (auxiliary)
APPLIANCE CLASS APPLIANCE CLASS APPLIANCE CLASS APPLIANCE CLASS APPLIANCE CLASS 3
APPLIANCE CA APPLIANCE CA APPLIANCE CA APPLIANCE CA APPLIANCE CATEGOR TEGOR TEGOR TEGOR TEGORY Y Y Y Y GB - IE: II2H3+
GAS SUPPL GAS SUPPL GAS SUPPL GAS SUPPL GAS SUPPLY Y Y Y Y Natural gas G20 (2H) 20 mbar
Instructions for the Installer
Engineer technical data Engineer technical data Engineer technical data Engineer technical data Engineer technical data
This appliance is manufactured according to the following EEC
directives:
2006/95 EEC - 2004/108 EEC - 2009/142 EEC, current edition.
