Electrolux ARCTIS No-frost (frost free) - Manual (Page 10)

Installation
10
The appliance needs ventilation
Air is fed under the door through the
vent slots in the base and is vented
upwards along the back wall. To
ensure proper air circulation never
cover or alter the vent openings.
Attention! If the appliance is
installed under, for example, a
hanging cabinet, a clearance of at
least 10 cm between the top of the
appliance and the cabinet above it
must be maintained.
0
1. Break both wall spacing elements
from the plinth and insert them into
the sockets at the back side of the
appliance, according to the figure,
so that the required wall gap for the
necessary ventilation at the back of
the appliance is provided for.
Appliance Alignment
0
1. The appliance must have a solid, level footing. Please compensate for
unevenness in the floor by turning the two adjustable feet at the front
in or out.
