Design LED 12 Brick
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free (866) 245-6726
COLORS
• LED panel with 12 LEDs
• 12 x 1W Luxeon LED’s - (4 Ea. R, G, B)
• Seamless RGB color mixing
• Infinite Color possibilities
PHOTOMETRICS
Design LED 12 Brick
Photometric Beam Angle Data
Beam Angle 44°
LUX x 0.0929 = FC
44°
Beam Angle
45 FC
480 LUX
13 FC
144 LUX
7 FC
76 LUX
0 m
0 ft
1 m
3.28 ft
3 m
9.8 ft
2 m
6.6 ft
Ø 0.8 m
Ø 2.6 ft
Ø 1.6 m
Ø 5.2 ft
Ø 2.4 m
Ø 7.9 ft
Beam Diameter
Ø 0.8m / Ø 2.6ft
Ø 1.6m / Ø 5.2ft
Ø 2.4m / Ø 7.9ft
