Displ
a
y
Driving page
GPS signal quality:
Instant spray rate /
Target spray rate /
Nozzles being used
Output percentage variation
Every symbol corresponds to a 10% variation:
+ 10% - 10% (max. ± 50%)
Via Palladio, 5/A - 42048 RUBIERA (RE) - Italy - tel. +39 0522 622011 - fax +39 0522 628944 - www.aragnet.com D20328_GB-m00
Speed /
Tank level
Nozzles being used /
Direction
Pressure /
Range
Sprayed area /
RPM
Distributed amount /
Calculated area
Boom sections:
Open section
Closed section
Zone already sprayed, close section
Zone to be sprayed, open section
Main valve closed
Tex
t editing
DGPS
signal GPS
signal Invalid
data
Active alarm (Press F1 for more details)
Led bar: graphic representation of the deviation Offset: distance between the tractor position
and track to be followed
Section management
Track number
Output setting
Machinery position
Reference tracks
Sprayed area
Legend:
job00
Entered name
|
Cursor Selected character Shift cursor across the
characters of the name Enables / disables upper
cases Deletes the character
before cursor Saves the entered text
Select job data
displayed on the LEFT side Select job data
displayed on the RIGHT side
Display zoom adjustment
F3 ( + ) zoom in, F5 ( - ) zoom out
View job information /
alarms
Go to “Home” menu
Confirmation key Abort a function
Go to job menu
View automatic function
menu
Enables / disables
job functions display
ON / OFF
Select character
Select character
Delete the character
before cursor - Confirms the selected
character
- Deletes the character
before cursor
(if the symbol “ ” is
selected)
- Saves the entered text
(if the symbol “ ” is
selected)
Quits the modification
without confirming it
Automatic function state:
