Step 1: The triangle brush w/angle
adaptor connects either
directly to the handgrip or
may be used with the
extension tubes. To connect
the extension tubes to the
hand grip attach the
extension tubes one onto the
other and then onto the hand
grip. (Fig. 11 & 12) To
disconnect, reverse the
operation by pressing the
locking button and pulling the
two sections apart.
Fig. 11
7
4. Fold the other side of the towel as
shown in Fig. 7.
Fig. 7
5. Place the corner under the cloth
holder as shown in Fig. 8.
Fig. 8
6. Place the towel around the brush,
and repeat folding the towel as shown
in Fig. 9. When folding the towel,
leave some slack. Do not pull tightly
around the brush, leave some
looseness.
Fig. 9
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS cont.
Attaching the Accessories to
the Flexible Steam Hose
Using Your Steam Cleaner
with Triangular Brush
WARNING: Always insure the
unit is “UNPLUGGED” from the
wall receptacle prior to attaching
or removing accessories.
To attach the triangular brush to the
angle adapter, hold angle adapter in
your right hand and the brush in your
left. Insert the angle adapter into the
triangular brush and turn 180° to lock
in place. (Fig. 10 )
Fig. 10
Fig. 12
Important: Please note that bristles may
break through thin towels. We recommend
that two (2) towels, laid one on top of the
other be used. This will ensure that the
brush bristles do not break through and
that the towels will be sufficiently absorbent
and retain as much dirt as possible.
Very Important : When installing the
towels to the triangular brush, ensure that
the towels do not cover the front and the
back of the brush. (See Fig. 16)
100% white terry cloth towel can be fitted
on this brush, so as to absorb the dirt and
protect delicate surfaces.
Fig. 13
1. Prepare white terry cloth towel:
size 8” x 17” as shown in Fig. 13.
2. Place the brush on top of the towel.
Fig. 14
3. Fold the towel
as shown in
Fig. 14
Fig. 15
Attaching a Towel to the
Triangular Brush
Dual Edge Glass & Tile Squeegee
This attachment is very useful for
cleaning large windows, plastic material,
ceramic, tiled or marble surfaces.
To use: Connect the tile
squeegee to the hand
grip or use with
extension tube for
hard to reach surfaces.
Apply steam abundantly, rub with the
soft spongy edge, then remove excess
water and dirt with the glass wiping
edge.
IMPORTANT: When cleaning
windows, always avoid any sudden
changes in temperature to prevent glass
breakage or cracks.
Concentrator
Attach the concentrator
to the handgrip or to the
extension tubes. Then
attach the detail brushes
To the concentrator.
Detail Brush
It is best for cleaning grout in-between
the tiles, ceramic and marble.
To use: Attach the detail
brush on to the end of the
concentrator, which
then may be used directly
on the hand grip or with extension tubes
4. Place the
corner under
the cloth
holder.
(Fig. 15)
5. Fold the other
side of the towel
in the same way
and place the
corner under the
cloth holder.
(Fig. 16)
Fig. 16
