ELK-M1XEP Installation Manual Page 3
FEATURES:
•
Web server with embedded Java applet "M1 Virtual Keypad"
•
Secure connection with password protection and HTTPS encryption
•
Flash Memory for Firmware Updating
•
Event notification via E-Mail (SMTP)
•
Supports automatic Dynamic DNS Updates with providers using the DynDNS protocol.
•
Supports Network Time Protocol for synchronizing the M1/EZ8’s clock with an Internet time server.
•
Internet Monitoring and Reporting Capability
•
TCP/IP stack supporting the following protocols:
TCP,UDP,DHCP,SSL 3.0/TLS 1.0, HTTP, SMTP
•
Federal Information Processing Standards (FIPS) 128 bit encryption
•
Integrated 802.3 compliant 10/100 Mbit network interface
•
RS232, DB9M 9-pin serial port connection
•
Connects to the M1 RS-232 Serial port (Port 0). The baud rate for this port must be set to 115,200 (factory default)
•
RJ45 8-pin Network Jack
•
2.1mm barrel type power connector (center positive)
•
LED Indicators for Power, Link, and Data
SPECIFICATIONS:
•
Operating Voltage: 12 Volts D.C. from Elk-P1216 Plug-in Power Supply **
•
Current Draw: approx. 300 mA
•
Housing Dimensions: 4.25" x 6.375" x 2.125"
•
Circuit Board Dimensions: 2.25" x 3.95"
** Any required network equipment, i.e. Ethernet switch, router, cable modem, etc. including the plug-in power supply for the
M1XEP, MUST be backed up with an adequately sized UPS (Uninterruptible Power Supply) in order for the equipment to con-
tinue operating during brief power outages.
Features and Specifications
APPLICATION:
The ELK-M1XEP is an Ethernet Device Server with a RS-232 Serial Port Interface. It may be used to connect a Control
in the M1 Family to an Ethernet network using TCP-IP protocol. It features a secure embedded web server with a user
interface built on a Java applet, email event notification, and FIPS compliant encryption algorithms for security sensi-
tive environments. It is powered by an ELK-P1216 12 Volts DC, 1.5 Amp plug-in power supply/adapter (included). A
software setup utility is built into ElkRP (version 1.5.0 or later) for configuring the connection setup, network password,
etc. The M1XEP is factory defaulted to obtain a dynamic IP address from a DHCP server (i.e. Ethernet switch, cable
modem, etc.), however it may also be setup with a static IP address.
RJ-45 Connector
LED Indicators
Description Normal State
Orange
Green
Processor Power Indicator
Network Traffic Indicator
On-Solid
On-Blinking
During a reboot, the green light will be off and the orange light will be on for
30-45 seconds. When the reboot is complete, both lights will be off for a
second, and then the orange light will come on solid and the green light will
begin to blink. Wait several seconds before re-establishing
a connection with the control.
