Elk M1XEP User Manual
Page 2
ELK-M1XEP Installation Manual
Page 2
Table of Contents
Features and Specifications .......................................................................................................... 3
Basics of Networking .....................................................................................................................4
Installation and Hookup ................................................................................................................. 5
Configuration and Setup ................................................................................................................ 6
Basic Network Setup ........................................................................................................................
6
Send Changes to M1XEP and Save ................................................................................................
8
Setup of User Names & Passwords ................................................................................................
8
Email Notification Setup ..................................................................................................................
9
Central Station Setup ....................................................................................................................
10
Dynamic DNS Setup .......................................................................................................................
12
Time Server Setup
................................................................................................................13
Audio Setup ..................................................................................................................................... 14
Notes on Router Setup ................................................................................................................... 14
Other Ports Used By the M1XEP ................................................................................................... 14
Connecting ElkRP to the Control over a Network ..................................................................... 15
Updating the M1XEP Firmware ................................................................................................... 16
Using the Virtual Keypad Application ......................................................................................... 17
Glossary of Terms ........................................................................................................................23
Troubleshooting Guide ................................................................................................................24
IMPORTANT NOTICE:
The M1XEP has been shipped with the non-secure port enabled.
It is strongly recommended that you configure the M1XEP to
use the secure port for communications outside of the local
network. If you will connect to the local network using the
non-secure port, it is strongly recommended that the M1XEP be
behind a network router. Do not port forward the non-secure
port to outside the local network. If the non-secure port will
not be used it should be disabled in the M1XEP setup (refer to
section 1.7 of the configuration and setup).
