CONTROLS AND COMPONENTS
NOTE:
PHOTOGRAPHS MAY SHOW NON-STANDARD EQUIPMENT AND OPTIONS
FIG. 18 Light Bar and Mounting Locations
1. Light Bar
2. Light mounting locations —Mount lights here
for use during operation 1
FIG. 17 Vertical Tower
1. Seven Section Vertical Tower
2. Light Mounting Locations --Mount lights
here for use during operation
3. Light connector sockets—attach light
leads to light bar at these female receptacles
when provided
2
2
3
1
FIGURE 17.
FIGURE 18.
