TCM-6630 Hardware User’s Manual
42

RUN SEQUENCE
User can command the speed dome camera to run the selected Sequence line manually.

EXIT
Select the item to exit the SEQUENCE menu.
AUTOPAN
Auto-pan means rotating or scanning side-to-side motion by a speed dome camera to view an area
horizontally. The parameters can be set on this page.

AUTOPAN LINE
There are four sets of auto-pan lines built in speed dome camera. Users are able to command
the speed dome camera to do continuously panning without limit by setting the start point the
same as endpoint.

START POINT
Follow the description to set the start position of the AUTOPAN path.
1. Move the cursor to and press while item flashes,
the item will turn automatically.
2. Move the speed dome to a desired position and press to save the position as
the start point; the cursor will move to automatically. Ensure to set the end
point to complete the auto-pan setting.

END POINT
Users are able to set the end point after the start point is defined. Pan the dome to another
position and press to save the position as the end point.
NOTE: The tilt and zoom value of the start point will be
recorded and fixed for the selected auto-pan line.
AUTOPAN
AUTOPAN LINE 1
START POINT TO FIND
END POINT TO FIND
DIRECTION RIGHT
SPEED 1
RUN AUTOPAN ENTER
EXIT YES
