Step 5: Attach the Camera to the Tray
1.
Position the camera on the plastic tray. Consider that the camera lens must touch or be as
close as possible to the glass panel when the camera is placed inside the housing.
2.
Tightly attach the screw (included in the outdoor housing package) to secure and fix the
camera on the plastic tray.
Metal Ring
Power Terminal
Connector
Heater
