Page 17
Installation Guide
How to Adjust the Viewing Angle and Focus
NOTE:
The following procedures are not applicable to E96 (Mini Fisheye Dome) cameras.
1.
Loosen the three (3) screws to remove the dome cover.
2.
Based on the live view from the camera, adjust the viewing angle with pan and tilt direction
(for Mini Dome models only).
