Installation – Elite Screens Universal User Manual
Page 3
Rev. 02811‐AS
www.elitescreens.com
3
1. Mark the location of where the WhiteBoardScreen
™
Universal will be installed and drill your
holes for all of the Top Hanging Brackets (d). Once the holes have been drilled, insert
and screw the wall screws (a) as shown below. It is strongly recommended to install the
WhiteBoardScreen™ Universal on wood studs for added stability. If the location does
not have wood studs, then use the included hollow wall (drywall) anchors (c).
2. Next, attach the tray (i) to the bottom of the WhiteBoardScreen
™
with the
three M3 SCREWS
(h) as shown below.
3. Hang the WhiteBoardScreen
™
Universal on the Top Hanging Brackets (d), making sure the top
lip inserts into the rail on back of the frame
Installation
Tray
M3 Screws
