Watson-Marlow 323Dz User Manual 46
21.5 313D and 314D: maximum number
of pumpheads
313D, 314D Pumpsil, to 400 rpm
bore
mm 0.5 0.8 1.6 3.2 4.8 6.4 8.0
in 1/50 1/32 1/16 1/8 3/16 1/14 5/16
# 112 13 14 16 25 17 18
0-0.5 bar 6 6 5 3 2 2 1
0.5-2 bar 6 6 5 3 2 1 1
313D, 314D Marprene, Bioprene, Tygon, Neoprene, Fluorel, to 400 rpm
bore
mm 0.5 0.8 1.6 3.2 4.8 6.4 8.0
in 1/50 1/32 1/16 1/8 3/16 1/14 5/16
# 112 13 14 16 25 17 18
0-2 bar 6 6 4 2 2 1 1
313D, 314D STA-PURE, CHEM-SURE, to 400 rpm
bore
mm 1.6 3.2 4.8 6.4 8.0
in 1/16 1/8 3/16 1/14 5/16
# 14 16 25 17 18
0-2 bar 1 1 1 1 1
313D2, 314D2 Pumpsil, Marprene, Bioprene, Tygon, Neoprene, Fluorel,
STA-PURE, CHEM-SURE, to 400 rpm
bore
mm 0.5 0.8 1.6 3.2 4.8 6.4 8.0
in 1/50 1/32 1/16 1/8 3/16 1/14 5/16
# 112 13 14 16 25 17 18
0-2 bar 1 1 1 1 1 1 1
Note: 314D pumpheads should run no faster than 300 rpm when in continuous use.
Speeds up to 400 rpm are permissible for intermittent use.
