MAINTENANCE
67
The torque on the bolts should be as given in
the table below.
3. Insert the lifting pole.
The lifting pole (C) is fastened on the bottom
side of the bracket with a bolt (D). Furthermore,
the lifting pole is supported by a ring (E), which
is placed in the hole of the bracket.
Bolt size Torque
M16 210 Nm (1860 lbf in.)
M20 400 Nm (3540 lbf in.)
WARNING
Do not exceed the maximum
allowed lifting weight of 200 kg/
440 lbs during the lifting of the
cover. This is also indicated on the
CLD.
