Sample wiring diagrams gas or electric heat, Page 17, Owner's manual – Venstar T0130 User Manual
Page 17: T0130
Page 17
Sample Wiring Diagrams
Gas or Electric Heat
5 Conductor 18 to 22 gauge
unshielded cable from the
thermostat to both sets of
equipment.
OWNER'S MANUAL
5 Conductor 18 to 22 gauge
unshielded cable from the
thermostat to both sets of
equipment.
Dual Transformer 5 Wire, 1 Stage Cooling, 1 Stage Heating
Residential Gas or Electric Heat, Electric Cool, split systems & package units.
For jumper configuration see pages 18 and 19.
Remove the
factory installed
jumper between
RC and RH
Heating System
FAN
G
W
GAS OR
ELECTRIC HEAT
W
GAS OR
ELECTRIC HEAT
R
H
POWER
HEAT
R
H
POWER
HEAT
Heating System
T0130
Common wire is optional in all installations. If a common wire is not used the
thermostat must be powered by two AA alkaline batteries. These batteries
must be replaced (page 10) each year or when the Low Battery indicator is
displayed (page 3).
*
Cooling System
COMPRESSOR
Y
R
C
POWER
COOL
Cooling System
C
RH
Y
W
G
RC
O/B
Common wire optional
*
