Auxiliary Input Control and Multiple HVAC Control

Potential Phasing Problems

Important Information About:

110vac

Isolation Relay

Coil

CK 1

R

Thermostat

CK 1

R

Thermostat

CK 1

R

Thermostat

Additional relays may be used. Relay coils must be wired in parallel.

Diagram A- Auxiliary Control

When using the auxiliary input (CK1 & R) or controlling multiple
HVAC units with a
transformer phasing problems that will
operation. Connecting transformers that are not phased
correctly may result in a direct short, which could damage the
transformers and/or the
if the units share a common ground with

single thermostat, it is possible to encounter

interfere with thermostat

thermostats. Phasing problems are likely

secondary grounded

transformers.

CAUTION

WARNING

SOLUTION: If possible, phase all HVAC units together.
If phasing is impractical,
the transformers. To isolate the auxiliary
transformer for the auxiliary control device, usually a time clock.
Connect the device to an isolation relay coil. Connect one set

each thermostat at CK1 and R.

See diagram A.

isolation relays may be used to isolate

input, use a separate

of isolated contacts to

Page 37

Sample Time Clock Wiring Diagram
