Dometic NDR1292-S User Manual

Page 7

CERTIFIED INSTALLATION

Certified installations require one roof vent and one lower
side vent.
For “Certified Vent System

page 14.

For further information contact your dealer or distribu-
tor.

FIG. 9

LOWER VENT CUTOUT

METHODS OF INSTALLATION

The method of installation is shown in FIG. 9. It is es-

s e n t i a l t h a t a l l m a x i m u m o r m i n i m u m d i m e n s i o n s a r e
strictly maintained as the performance of the refrigera-

tor is dependent on adequate flow of air

the rear of

the refrigerator.

NOTE: The

vent should be centered

the

condenser coil at the back of the refrigerator.

VENTILATION HEIGHTS

CLEARANCES

Minimum clearances in inches to combustible materials

Side

Bottom 0

N :

S e e N O T E : C l e a r a n c e

b e l o w .

NOTE: Clearance

is between the

part of

the refrigerator and the wall behind the refrigerator.

NOTE: Clearance “N” is the distance between the bot-
tom of the lower vent to the roof material. For ventilation
height, see table VENTILATION HEIGHTS
See Figures 9, and 10.

NOTE: Wood Strip
MUST be in place

FIG. 10
