30
TRI TOOL INC.
92-0579 Rev. 130308
Parts List, Model 301SP
Item Part
No. No. Description Qty
1 14-0006 SHAFT, ASSY 1
2 19-0736 HOUSING 1
3 20-0016 SHAFT 1
4 29-0028 BEARING, ROLLER 2
5 30-0062 RING, RETAINING, EXTERNAL, 1/2" DIA. 1
6 30-0063 RING, RETAINING, EXTERNAL, 1 3/8" DIA. 1
7 30-2278 GRIP 1
8 SADDLE REF
9 32-0026 PIN, ROLL, 1/8" DIA. X 3/4" 1
10 33-0030 SCREW, CAP, #10-24 X 3/4" 3
11 33-0041 SCREW, CAP, 1/4-20 X 7/8" 1
12 33-0285 SCREW, 1/4-20 X 1/2", BUTTON 2
13 33-0501 SCREW, SET, 1/4-20 X 3/8", CUP PT 1
14 33-0499 SCREW, SET, 1/4-20 X 1/4" 3
15 33-1924 SCREW, SHOULDER, 1/4" DIA. X 1 1/2", 5/32" HEX 1
16 34-0304 WASHER, FLAT, 1/4" ID 2
17 34-0059 WASHER, FLAT, DELRIN 1
18 34-0060 WASHER, FLAT, DELRIN 1
19 35-0045 NUT, INT. HEX, 1/2-20 1
20 40-0035 SPRING, COMPRESSION 1
21 41-0018 HANDLE 1
22 42-0146 KNOB ASSY., ADJUST 1
23 46-0014 SLEEVE 1
24 46-0016 SLEEVE 1
25 46-0480 SLEEVE, INDICATOR 1
26 27-0614 ADAPTOR, INDICATOR 1
27 33-0013 SCREW, CAP, #6-32 X 1/2" 2
