21
ENGLISH
Specifications
Item Specification
Product name Liquid crystal projector
Liquid Crystal Panel 1,024,000 pixels (1280 horizontal x 800 vertical)
Lamp 210W UHP
Speaker 10W
Power supply AC 100-120V/3.1A, AC 220-240V/1.6A
Power consumption AC 100-120V:310 W, AC 220-240V:300W
Temperature range 5 ~ 35°C (Operating)
Size
345 (W) x 85 (H) x 303 (D) mm
* Not including protruding parts. Please refer to the following figure.
Weight (mass) approx. 3.8 kg
Ports
Computer input port
COMPUTER IN1
....................... D-sub 15 pin mini x1
COMPUTER IN2
....................... D-sub 15 pin mini x1
Computer output port
MONITOR OUT
....................... D-sub 15 pin mini x1
Video input port
S-VIDEO ..............mini DIN 4 pin x1
VIDEO .................................RCA x1
HDMI input port
HDMI ............... HDMI connector ×1
Audio input/output port
AUDIO IN1 ................ Stereo mini x1
AUDIO IN2 ................ Stereo mini x1
AUDIO IN3 (R, L) ................. RCA x2
AUDIO OUT (R, L) ............... RCA x2
Others
USB TYPE A ......................USB-Ax1
USB TYPE B .....................USB-Bx1
CONTROL ................. D-sub 9 pin x1
LAN ..................................... RJ45 x1
MIC .............................. Mono mini x1
Optional parts
Lamp:456-8104
Filter set: UX37191
Mounting accessary:
Laser remote control: RC-R008
* For more information, please consult your dealer.
[unit: mm]
8104HW-WALLARM Wall mount for the 8104HW
