Thermon ZP-PTD100-XP Terminator - Manual (Page 3)

2.
1.
3.
Insert banding guide into expediter and snap into place.
Mount expediter to pipe using pipe band.
Tighten cap securely.
B-type banding
- order separately
B-4: for pipes up to 4”
B-10: for pipes up to 10”
B-21: for pipes up to 21”
12
10
PTD-100 temperature sensor kit
- order separately
11
Kit Contents Installation Instructions 2
Mount junction box base on expediter. Make sure to align
slots to properly orient junction box base. Tighten nut with
Terminator-LN-Tool.
4.
