105270-01G
For more information, visit www.desatech.com For more information, visit www.desatech.com
31
31
KEY PART NUMBER
NO. FPVF33PR FPVF33NR DESCRIPTION QTY.
1 102785-02 102785-02 Log, Golden Oak 1
2 103778-01 103779-01 ODS Pilot 1
3 098249-01 098249-01 ODS Nut 2
4 099387-09 100609-01 Pilot Tube 1
5 104229-02 104229-01 Burner Outlet Tube 1
6 111124-01 111124-01 Burner Retainer Spring 1
7 099056-19 099056-26 Burner Orifice Injector 1
8 102772-01 102772-01 Burner 2
9 M11084-38 M11084-38 Screw, #8 x .38 2
10 104236-01CK 104236-01CK Painted Base Assy 1
11 M12461-26 M12461-26 Screw, #10 x .32 4
12 ** ** Firebox Bottom 1
13 103284-03 103284-03 Wiring Harness 1
14 098265-02 098265-02 Elbow, Male 1
15 103782-01 103782-01 Valve Bracket 1
16 103781-02 103781-01 Gas Control Valve 1
17 098271-03 098271-03 Ignitor Cable 1
18 102445-01 102445-01 Piezo Ignitor 1
19 098304-01 098304-01 Screw 7
20 099998-01 099998-01 Switch 1
21 104241-01 104241-01 Remote Switch Bracket 1
22 103587-01 103587-01 Switch Plate 1
23 097809-02 097809-02 Male Connector 1
24 101628-03 101628-03 Flexible Connector (Hose) 1
25 M50104-02 M50104-02 Bushing 1
26 M11084-26 M11084-26 Screw, #10 x .38 4
27 ____ 099918-02 Pilot Regulator 1
28 ____ 099387-07 Pilot Tube (Valve to Regulator) 1
** Not a field replaceable part.
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 36 of this manual.
PARTS LIST
Models FPVF33PR and FPVF33NR
