Outline description.
The SMT8096 is PCI based and stands as an evaluation/development platform as
part of a Multi-carrier / Multi-standard cellular system, MIMO infrastructure, Test
Equipment, etc…
The SMT8096 is a PCI system based on 3 main modules: TI DSP C6416T module
(SMT395-VP30-6) combined with a dual high-speed ADC/DAC mezzanine SLB
module (SMT350) and an SLB base module (SMT368), all plugged on a PCI carrier
board (SMT310Q).
SMT395-VP30-6 characteristics:
⇒
1GHz TMS320C6416T fixed-point DSP,
⇒
8000 MIPS peak performance,
⇒
Xilinx Virtex-II Pro VP30-6 FF896 package,
⇒
Six 20MB/s communication ports (Comports),
⇒
256MBytes of SDRAM (133MHz),
⇒
8MByte Flash ROM for boot code and FPGA programming,
⇒
Global expansion connector,
⇒
High bandwidth data I/O via 2 Sundance High-speed Buses (SHB),
⇒
JTAG Diagnostics port.
SMT350 characteristics:
⇒
Two 14-bit ADCs (TI – ADS5500) sampling at up to 105MHz,
⇒
Dual 16-bit DAC (DAC5686) sampling at up to 500MHz (interpolation),
⇒
One Sundance LVDS Bus (SLB – 60-way Samtec SQH),
⇒
Low-jitter on-board system clock based around the combination of a VCXO
and the TI - CDCM7005,
⇒
50-Ohm terminated analogue inputs and outputs, external triggers and
clocks via MMCX (Huber and Suhner) connectors.
SMT368 characteristics:
⇒
Virtex 4-SX (XCV4SX35 FPGA) in an FF668 package,
⇒
Two banks of 8Mbytes of ZBTRAM,
⇒
Four Sundance High-speed Bus (SHB – 160 I/Os),
⇒
Two Comport,
⇒
One Sundance LVDS Bus (SLB – 60-way Samtec SQH).
