10.4.2 Online-Access to all Parameters
Via RS-232 connection and using REMOTE-commands provides direct access to all DRM 4000 parame-
ters, like routing, VCA, priority override, ducking, mute, etc. Controlling the unit is possible parallel to any
other control method (hardware contact switching, software contact switching, external VCA-control), with
any individual priority being recognized. For example, activating an external contact with a higher priority
setting overrides actual remote settings. As soon as deactivating the contact again, all previous remote
are regained.
Generally, all REMOTE-commands have the lowest priority (0) and all entries are set to NO_CHANGE.
The following table lists all REMOTE-commands and their corresponding parameter values.
Please be aware of the fact that all REMOTE-commands are transient and are set back to their default
values (NO_CHANGE, priority 0) upon switching the unit’s power on or after resetting the device.
ASCII-command Comment
/SERVICE/HB value Value: 60 ... 0, OFF / ? (see above)
/SERVICE/CC/ON value Value: NONE, 1-8 / ? (see above)
/SERVICE/CC/OFF value Value: NONE, 1-8 / ? (see above)
/REMOTE/PRIO value
e. g.:
/REMOTE/PRIO 100
/REMOTE/PRIO ?
Value: 0 ... 255 / ? ( 0 = lowest, 255 = highest priority)
Write access: assigns a priority to REMOTE-commands.
Read access: reads a REMOTE-command’s actual priority.
/EDIT/REMOTE/MIC_LINE1/ROUTING value
e. g.:
/EDIT/REMOTE/MIC_LINE1/ROUTING MONO_A
/EDIT/REMOTE/MIC_LINE1/ROUTING ?
Value: NO_CHANGE, OFF, MONO_A, MONO_B, DUAL / ?
Write access: sets the routing of MIC/LINE 1 via remote (mind
priorities!)
Read access: reads the routing of MIC/LINE 1, which has been set via
remote.
/EDIT/REMOTE/MIC_LINE1/OVERRIDE value
e. g.:
/EDIT/REMOTE/MIC_LINE1/OVERRIDE ON
/EDIT/REMOTE/MIC_LINE1/ OVERRIDE ?
Value: ON, OFF / ?
Write access: activates or deactivates priority override of MIC/LINE 1
via remote (mind priorities!)
Read access: returns the actual status.
...
ROUTING for MIC_LINE2 … MIC_LINE4 see MIC_LINE1
OVERRIDE for MIC_LINE2 see MIC_LINE1
/EDIT/REMOTE/MIC_LINE4/... ...
/EDIT/REMOTE/AUX1 value
e. g.:
/EDIT/REMOTE/AUX1 STEREO
/EDIT/REMOTE/AUX1 ?
Value: NO_CHANGE, OFF, MONO_A, MONO_B, DUAL, STEREO / ?
Write access: sets the routing of AUX 1 via remote (mind priorities!)
Read access: reads the routing of AUX 1, which has been set via
remote.
... …
/EDIT/REMOTE/AUX4 value ROUTING for AUX2 … AUX4 see AUX1
/EDIT/REMOTE/OUT_A/MUTE value
e. g.:
/EDIT/REMOTE/OUT_A/MUTE OFF
/EDIT/REMOTE/OUT_A/MUTE ?
Value: NO_CHANGE, ON, OFF / ?
Write access: sets the status output relay in the MASTER A output via
remote (mind priorities!)
Read access: reads the actual status.
/EDIT/REMOTE/OUT_A/DUCK value
e. g.:
/EDIT/REMOTE/OUT_A/DUCK ON
/EDIT/REMOTE/OUT_A/DUCK ?
Value: NO_CHANGE, ON, OFF / ?
Write access: sets the status of the ducking control in the MASTER A
output via remote (mind priorities!)
Read access: reads the actual status.
/EDIT/REMOTE/OUT_A/LEVEL value
e. g.:
/EDIT/REMOTE/OUT_A/LEVEL -10
/EDIT/REMOTE/OUT_A/LEVEL ?
Value: NO_CHANGE, -90 ... 0 / ?
Write access: sets the VCA of the MASTER A output via remote to
the desired value (mind priorities!)
Read access: reads the actual status.
... ...
/EDIT/REMOTE/OUT_B/... OUT_B settings see OUT_A
/EDIT/ACTUAL/...
e.g..: /EDIT/ACTUAL/MIC_LINE1/ROUTING? Reads the actual states of the DRM 4000 like routing etc.
Only read access is recommended.
