Pump linkage parts list – Smithco Tournament Roller Ultra Lite 7575 Parts & Service Manual User Manual
Page 15
PUMP LINKAGE PARTS LIST
REF.#
PART#
DESCRIPTION
QTY.
1
750-800
Pump
1
2
750-228-30
Bushing
1
3
750-343-1
Shift Lever Top (New)
1
3
750-343
Shift Lever Top (Old)
1
4
750-344-1
Shift Lever Bottom (Sq. Hole .470)
1
4
750-344
Shift Lever Bottom (Sq. Hole .350)
1
5
750-228-31
Bushing
1
6
750-345
Shift lever Right
1
7
750-229-1
Gold Spring
1
8
750-228-32
Nylon Washer
1
9
750-346
Shift Lever Left
1
10
750-228-33
Nylon Washer
1
11
750-228-34
5/16” Flat Washer
2
12
750-228-35
Allen Head Bolt
1
13
750-228-36
Allen Head Bolt
1
14
750-228-37
Pump Bracket Kit
1
13
