HYDRAULIC PLUMBING PARTS LIST


REF#

PART#

DESCRIPTION

QTY.

1

750-916

Oil Tank

1

2

750-825

Left Roller Housing

1

3

750-826

Right Roller Housing

1

4

750-302

Filter Head

1

5

750-801

Wheel Motor

2

6

750-847

16cc without Aug Charge Pump

1

7

750-326

Wheel Motor Fitting

4

8

750-325

Oil Filter Head Fitting

2

9

750-322

Pump Fitting

2

10

750-324

Pump Fitting Top

1

11

750-295

Pump Fitting

1

12

750-920-1

Hyd Hose 5

7” x ½” (w/o 90° to Straight)

1

13

750-502

Hard Line Clamp

2

14

750-920-2

Hydraulic Hose

14” – Pump to Filter

1

15

750-920-3

Hydraulic Hose 35

2

16

750-920-4

Hydraulic Hose

11” – Oil Tank to Filter Head

1

17

750-920-5

Hydraulic Hose

7” – Oil Tank to Pump

1

18

750-519

Hard Line Long Left Side

1

19

750-520

Hard Line Short Left Side

1

20

750-506

Hard Line Long Right Side

1

21

750-507

Hard Line Short Right Side

1

22

750-923

Drain Cap

1

23

750-920-6

Drain Hose

1

24

750-920-7

Hydraulic Hos

e 52”

1


NOTE: OIL FILTER IS A PART# 750-300

COMPLETE HOSE KIT IS A PART# 750-920
