Smithco Super Star X-Treme Gas 43-000-x (sn 43375 – Current) Parts & Service Manual - Manual (Page 65)

A-17
Front Attachment
40" ANGLE PLOW PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-346 Lift Assembly 1
2 HNTL-12-13 Lock Nut 1 /
2
- 13 4
3 HB-12-13-200 Bolt 1 /
2
- 13 x 2 4
HMB-12-14 Machine Bushing 1 /
2
x 14GA 8
4 80-006 Rod End 4
HNJ-12-20 Jam Nut 1 /
2
- 20 4
5 27-073 Lift Rod 2
6 27-017 Aluminum Sand Plow Blade 1
7 42-495 Pivot Frame 1
8 HCP-58-250 Clevis Pin 5 /
8
x 2 1 /
2
2
HHP-18 Bridge Pin 1 /
8
2
9 HB-58-11-300 Bolt 5/8 -11 x 3 1
HNTL-58-11 Lock Nut 5/8 - 11 1
10 42-456 Plow Mount 1
11 HB-38-16-100 Bolt 3 /
8
- 16 x 1 4
12 13-167 Wear Blade 1
13 HNFL-38-16 Flange Whiz Lock Nut 3 /
8
- 16 4
14 HB-12-13-200 Bolt 1 /
2
- 13 x 2 2
HNTL-12-13 Lock Nut 1 /
2
- 13 2
15 HB-38-16-125 Bolt 3 /
8
- 16 x 1 1 /
4
4
HW-38 Washer 3 /
8
4
HWL-38 Lock Washer 3 /
8
4
HN-38-16 Nut 3 /
8
- 16 4
16 HB-38-16-250 Bolt 3 /
8
- 16 x 2 1 /
2
2
HNTL-38-16 Lock Nut 3 /
8
- 16 2
17 HB-38-16-250 Bolt 3 /
8
- 16 x 2 1 /
2
2
HW-38 Washer 3 /
8
4
HNTL-38-16 Lock Nut 3 /
8
- 16 2
18 42-458 Right Pusher Bar 1
19 42-348 Rod 1
20 HCP-12-150 Clevis Pin 1 /
2
x1 1 /
2
2
21 HHP-18 Bridge Pin 1 /
8
2
22 42-347 Lift Handle 1
18-221 Flange Bushing 2
23 15-019 Grip 1
24 HP-18-150 Cotter Pin 1 /
8
x 1 1 /
2
1
HMB-34-14 Machine Bushing 3 /
4
- 14GA 1
25 42-459 Left Pusher Bar 1
