Smithco Super Star X-Treme Gas 43-000-x (sn 43375 – Current) Parts & Service Manual - Manual (Page 125)

C-21
Rear Attachment
13-758 MAX FLEX SAND RAKE
REF# PART# DESCRIPTION QUANTITY
1 HB-58-11-400 Bolt, 5 /
8
- 11 x 4 2
HMB-58-14 Machine Bushing, 5 /
8
x 14GA 2
HNCL-58-11 Lock Nut, 5 /
8
- 11 2
2 43-145 Drawbar 1
3 HCP-12-150 Clevis Pin, 1 /
2
- 1 1 /
2
2
4 HP-18-100 Cotter Pin, 1 /
8
x 1 2
5 76-275 Spacer 2
6 13-762 Right Rake 1
7 13-759 Grooming Blade 3
8 HB-516-18-075 Bolt, 5 /
16
- 18 x 3 /
4
6
HNFL-516-18 Flange Lock Nut, 5 /
16
- 18 6
9 HBFL-516-18-100 Flange Lock Bolt, 5 /
16
- 18 x 1 20
HNTL-516-18 Nylon Lock Nut, 5 /
16
- 18 20
HW-516 Flat Washer, 5 /
16
20
10 13-757 Rake Connect Strap 10
11 13-761 QH Center Rake 1
12 13-443 Finishing Blade 5
14 13-763 Left Rake 1
13* 13-445 Rake Teeth Kit (27 Studs and Hardware) 1
INSTALLATION INSTRUCTIONS
1. Bolt rake teeth (Ref 13) to frames, keeping all the same length.
2. Lay out rake frames (Refs 6, 11 & 14). Connect them using Clevis Pin (Ref 3), Spacer (Ref 5) and Cotter
Pin (Ref 4).
3. Attach Left Frame (Ref 14) and Right Frame (Ref 6) to Drawbar (Ref 2) using 5 /
8
Bolt, Machine Bushing,
and Center Lock Nut (Ref 1).
4. Attach the three Groomer Blades (Ref 7), one to each of the Rake Frames (Refs 6, 11 & 14) using two
Hex Bolts and Flange Lock Nuts (Ref 8). Slide Groomer Blades to end of slot and tighten hardware.
5. Attach the five Finishing Blades (Ref 12) to the tabs of the rake frames using two Rake Connect Strap (Ref
10) per Finishing blade. Secure using Flange Lock Bolt, Flat Washer and Nylon Lock Nut (Ref 9).
NOTE: Attach Straps using hardware as illustrated, placing Flat Washer on Strap then secure
with Lock Nut. Attaching with the Flange Bolt in contact with the Strap will cause the Strap to
bind and misalign Finishing Blade.
6. Attach the rake to the trap rake quick hitch by sliding the the drawbar hitch into the spring loaded locking
mechanism.
7. With the rake on the ground pull the rake to the right side until it is 2-3 inches from the tire.
8. Repeat steps on left side.
9. Turn machine on and test for operation of rake assembly by raising and lowering the rake assembly. Also
with rake down, turn sharp corners to check that rake does not touch wheels.
10. NOTE: Test rake in sand to assure tire tracks are covered by the rake when turning sharp corners in
either direction. If there are tire tracks, readjust using the adjusting screws on the hitch, so the rake
comes closer to the tire.
