Smithco Super Star X-Treme Gas 43-000-x (sn 43079 – 43174) Parts & Service Manual - Manual (Page 50)

A-5
Front Attachment
43-003 HYDRAULIC SAND PLOW PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-38-16-350 Bolt, 3 /
8
- 16 x 3 1 /
2 (Part of machine) 2
HW-38 Washer, 3 /
8
2
HNTL-38-16 Lock Nut, 3 /
8
- 16 2
2 18-188 45° Elbow 6
3 78-417 Straight Handle Kit 1
4 HB-14-20-200 Bolt, 1 /
4
- 20x 2 2
HNFL-14-20 Flange Whiz-Lock Nut, 1 /
4
- 20 2
5 13-731 Single Bank Hydraulic Valve 1
6 43-050 Valve Mount 1
7 HB-12-13-200 Bolt, 1 /
2
- 13 x 2 2
HNTL-12-13 Lock Nut, 1 /
2
- 13 2
HMB-12-14 Machine Bushing, 1 /
2
x 14GA 2
8 42-836 Spacer 2
9 80-006 Rod End 2
10 42-346 Lift Assembly 1
11 HP-18-100 Cotter Pin, 1 /
8
x 1 1
12 14-534 Hydraulic Cylinder 1
13 HB-38-16-200 Bolt, 3 /
8
- 16 x 2 2
HNTL-38-16 Lock Nut, 3 /
8
- 16 2
14 HNJ-12-20 Jam Nu,t 1 /
2
- 20 2
15 27-073 Lift Rod 2
16 27-017 Aluminum Sand Plow Blade 1
17 HB-38-16-100 Bolt, 3 /
8
- 16 x 1 4
HNFL-38-16 Flange Whiz Lock Nut, 3 /
8
- 16 4
18 13-167 Wear Blade 1
19 HB-38-16-125 Bolt, 3 /
8
- 16 x 1 1 /
4
2
HW-38 Washer, 3 /
8
2
HWL-38 Lockwasher, 3 /
8
2
HN-38-16 Nut, 3 /
8
- 16 2
20 HB-38-16-250 Bolt, 3 /
8
- 16 x 2 1 /
2
2
HW-38 Washer, 3 /
8
4
HNTL-38-16 Lock Nut, 3 /
8
- 16 2
21 HB-12-13-300 Bolt, 1 /
2
- 13 x 3 2
HNTL-12-13 Lock Nut, 1 /
2
- 13 2
22 27-050 Right Pusher Bar 1
23 HCP-12-150 Clevis Pin, 1 /
2
x1 1 /
2
3
24 HHP-18 Bridge Pin, 1 /
8
2
25 27-049 Left Pusher Bar 1
26 42-096 Cylinder Lift 1
27 HSTP-516-18-100 Machine Screw, 5 /
16
- 18 x 1
(on machine)
28 HLC-A-58 Loom Clamp 1
29 18-168 Elbow 90° 2
30 43-048 Hose, 20" 1
31 43-047 Hose, 57½" 1
32 Valve (on machine) 1
33 43-049 Hose, 18" 1
34 43-156 Hose, 75" 1
