C-45
Rear Attachment
42-581 GREEN STAR RBS ROLLER SET (3) PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-574 Fork 3
2 18-295 Oilite Bushing (part of 42-574) 6
3 HB-38-16-150 Bolt 3 /
8
- 16 x 1 1 /
2
12
HWL-38 Lock Washer 3 /
8
12
HW-38 Washer 3 /
8
12
HN-38-16 Nut 3 /
8
- 16 12
4 11-094 Pillow Block 6
5 42-584 Roller 3
6 42-539 Lynch Pin 5 /
16 (part of main frame) 3
7 42-586Q Green Star RBS Main Frame 1
ADJUSTMENTS AND OPERATION INSTRUCTIONS
ADJUSTMENT
The springs are preset for maximum down pressure, and should not need to be adjusted. If you feel the need to
adjust the springs please call for further instructions. The unit comes pre-adjusted for most models. The four
adjustment holes on the hitch are for making sure all three rollers are touching the ground at the same pressure.
When installing roller system start with the lower mounting holes on hitch.
Tire pressure should be 4 psi in the front and 7 psi in the rear tire for best traction.
OPERATION
Make sure the rolling system has been installed and adjusted properly for your model of bunker rake. Always
transport in fully raised position. Always remove flag pole before rolling green. Do not stop on green while rolling.
Do not roll up steep slopes or loss of traction may result. Do not turn while rolling.
To begin rolling, lower unit all the way down as you come across collar and continue straight across green until
reaching other collar and raise as you come off of green. Overlap stripes the same as if you were mowing.
