45
Accessories
42-401 MANUAL LIFT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HP-18-100 Cotter Pin 1 /
8
x 1 3
2 HCP-12-250 Clevis Pin 1 /
2
x 2 1 /
2
3
HW-12 Washer 1 /
2
8
3 Bolt 1 /
2
-13 x 5 4
Lock Nut 1 /
2
- 13 4
4 Attachment Mount 2
5 42-383 Flat Spring Bracket 2
6 42-384 Offset Spring Bracket 2
7 21-445 Spring 2
8 Attachment Lift 1
9 HB-38-16-125 Bolt 3 /
8
- 16 x 1 1 /
4
3
HNTL-38-16 Lock Nut 3 /
8
- 16 3
10 42-382 Lift Handle Mount 1
11 HSSQ-38-16-250 Square Head Set Screw 3 /
8
- 16 x 2 1 /
2
1
12 HB-516-18-400 Bolt 5 /
16
- 18 x 4 1
HW-516 Washer 5 /
16
2
11-055 Die Spring 1
HNFL-516-18 Flange Whiz Lock Nut 5 /
16
-18 1
13 42-381 Attachment Lift Handle 1
15-019 Round Grip 1
14 42-385 Handle Lock Bracket (Bolts to LH Floorbaord) 1
HSTP-516-18-150 Phillips Machine Screw 5 /
16
- 18 x 1 1 /
2
3
HW-516 Washer 5 /
16
3
HNTL-516-18 Lock nut 5 /
16
- 18 3
