Jack
Description
11
AV 1 audio in
To connect the Audio corresponding to AV1 source
12
AV 2 in
To connect the AV2 Video source.
13
AV 2 audio in
To connect the Audio corresponding to AV2 source
14
AV 3 audio in
To connect the Audio Corresponding to AV3 source
15
AV 3 in
To connect the AV3 Video source.
16
Headphone
Provides L&R Audio output to connect a set of
headphones.
Bottom View
#
Jack
Description
1
PC Audio
Accepts the Audio signal from your PC or Laptop.
2
ANT
Connect the coaxial cable (75 Ohm) or antenna here.
3
D-sub
Connects to D-sub 15 pin analog RGB Video from your
PC or Laptop.
4
AC in
Connect the power cord supplied to this terminal and then
turn on the Main Power switch right next to power cord
terminal.
