Proc Phase
This is Chroma (C channel) phase adjustment, expressed in degrees, ranging from –360 to +360 in
steps of one degree.
Framesync Submenu
Menu Structure Parameter Type
FS Enbl Frame Sync Enable
HOS Horizontal Offset
VOS Vertical Offset
LATF Frame Latency
ADLY Audio Delay
VDLY Video Delay
RSET Frame Sync Reset
Frame Sync Enable
Enables the frame sync. If disabled the output video timing matches the input video timing.
Horizontal Offset
Allows the user to specify an additional horizontal offset between the output video and the frame sync
reference in sample clock periods. These are sample clocks in the reference format, not the output
video format. For example, if using SD black burst to time 720p59.94 video each sample clock is 37ns,
not 13.5ns.
Vertical Offset
Allows the user to specify an additional vertical offset between the output video and the frame sync
reference in lines. These are lines in the reference format, not the output video format.
Frame Latency
Specifies the smallest amount of latency allowed by the frame sync. This latency measurement is in
frames of the output video. The frame sync will not output a frame unless the specified number of
frames are captured in the buffer. Minimum latency is three lines and zero frames in all video modes.
The maximum latency is format dependent. The operational latency of the frame sync is always
between the specified minimum latency and minimum latency plus one frame (not one field).
Audio Delay
Specifies the amount of additional audio delay after matching video delay. When the change is under
one and a half frames, the change in audio delay will be applied without interrupting audio. When
changing audio delay more than a frame and a half at a time, there will be a slight audio glitch.
Video Delay
Reports the current amount of video delay in ms.
Reset Frame Sync
Resets the frame sync, clearing any buffered audio and video. You must reset the framesync after
manipulating the horizontal and vertical offset in order re-establish correct audio and video co-timing.
