7
Gasket requirements and application
• There are 2 sizes of gasket strips included in the accessory pack with the
owner’s manual.
– 5 long gaskets.
– 1 short gasket.
• The gaskets are to be applied as follows:
– 2 long gaskets on back of enclosure.
– 2 gaskets on each side of enclosure to be placed against joist or
framing material.
– The short gasket is provided to run on the side of the enclosure where
the terminal cut-away is located.
Connecting the speaker
• Run color-coded wires between the speaker cavity and amplifier
unit. When running the wires inside the ceiling to the opening, leave a
minimum of 18" of additional length in the cavity to facilitate speaker
connection.
• Fish wiring out of hole.
• Connect the speaker wires to the UIW RCS II taking care to make red to
red (+) and black to black (-) terminal connections.
• Refer to your amplifier or receiver loudspeaker wiring instructions, turn
off the unit and connect the speaker wires to the appropriate colored out-
put terminal on the unit, again making red to red (+) and black to black (-)
connections. This will ensure absolute phase throughout the system.
Securing speaker
• Installation of this product must follow all local and state building
code requirements.
• We strongly recommend using a qualified, professional installer who is
knowledgeable of local building codes.
• We recommend holding the unit by the bezel and outer edges
of the speaker to avoid damaging the drivers.
• Place speaker in hole and secure to joists (or framing material) with
4 screws provided. Tighten 2 screws on one side before installing and
tightening the opposing side.
