*Design and specifications are subject to change without notice.
*“Dolby”, “Dolby Digital”, “Pro Logic”, and the double-D device are registered trademarks of Dolby Laboratories Licensing Corporation.
*DTS is registered trademarks of DTS Technology.
* , HDCD
® , High Definition Compatible Digital ® and Pacific Microsonics TM are either registered trademarks or trademarks of Pacific Microsonics, Inc. in the United States and/or other countries.
* PureProgressive TM Technology brought to you by Silicon Image, Inc.
Specifications
■ Video Section
Signal system ....................... NTSC
Disc played ........................... DVD Video, Video CD, Music CD, CD-R/RW (audio), CD-R/RW (MP3)
Video outputs ........................ Composite Video Output: 1.0 Vp-p (with 75 ohms load)
S-Video Output: Y; 1.0 Vp-p (with 75 ohms load), C; 0.286 Vp-p
Component Video Output: Y, Cb/Pb, Cr/Pr:
Y; 1.0 Vp-p (with 75 ohms load),
Cb/Pb; 0.648 Vp-p (with 75 ohms load),
Cr/Pr; 0.648 Vp-p (with 75 ohms load)
■ Audio Section
Audio outputs ....................... Analog Ouput (L/R): 2.0 Vrms
1 Set Optical Digital Output
1 Set Coaxial Digital Output
Signal-to-noise ratio ............. 115 dB (DVD/CD)
Dynamic range ..................... 108/100 dB (DVD/CD)
Total harmonic distortion ...... 0.0018 %
■ General
Power supply ........................ AC 120 V, 60 Hz
Power consumption .............. 19 W
Dimensions ........................... 434 (W) x 133 (H) x 330 (D) mm
17.1” (W) x 5.2” (H) x 13.0” (D)
Weight .................................. 7.0 kg, 15.4 lbs
N E W M O D E L I N F O R M A T I O N DVD-2800
■ PureProgressive TM Technology brought to you by Silicon
Image, Inc.
■ Video Controls
The DVD-2800 provides 5 video adjustment controls---Contrast,
Sharpness, Brightness, Gamma (to enhance gradation for video programs
with predominantly dark Progressive Scan images), and Hue (for
Interlaced images only)---which let you adjust the video images to suit your
taste.
■ MP3 Playback (*1)
The DVD-2800 also plays MP3 files downloaded from the Internet and
other sources. Simply record these files onto a CD-R/RW disc via your
computer, then play the disc in the DVD-2800.
■ CD-R/RW (audio/MP3) Playback (*1)
Both CD-R and CD-RW discs can be played in the DVD-2800.
■ 24-bit, 96-kHz Audio D/A Converter
The DVD-2800 uses a highly accurate multi-bit Sigma Delta D/A converter
with superior dynamic range and S/N characteristics. This converter pro-
vides plenty of support for the demanding 24-bit, 96-kHz sampling signals
of the DVD-Video format. The incorporation of a differential circuit in the
output stage and other features of the D/A converter ensure that playback
sound is of the highest quality possible, the normal expectation from
DENON’s acclaimed digital technology.
■ HDCD Decoder
HDCD is a digital recording technology, compatible with the conventional
CD format, that significantly reduces distortion during recording to expand
the dynamic range and realize high resolution. The HDCD decoder allows
the DVD-2800 to play discs that have been recorded in HDCD format
and to bring out the superior sonic performance from these discs.
Combined with DENON's advanced audio technology, the DVD-2800
masterfully reproduces HDCD's rich dynamic range and beautiful sound
quality.
■ Double-speed Drive System
The DVD-2800 employs a 2x drive system that drives at 4x when the
loaded disc is a CD. This unit is also equipped with a 4 MB buffer
memory to ensure that both picture and sound are played without
interruption when the DVD disc shifts from layer 1 to layer 2, or in the
rare event of a pickup dropout.
■ PCM, Dolby Digital and DTS Digital Output
■ 24/96 PCM Digital Output Capability
■ On-screen Display
■ Passes Below Black
DVD-2800 can pass below black video via the progressive and the
interlaced outputs for correct monitor setup and optimum picture quality.
■ Virtual Surround Mode (*2)
Surround yourself with sensational 3D soundfield envelopment using
just one pair of speakers. The DVD-2800's Virtual Surround mode
provides a dramatic psychoacoustic surround sound effect, using two
speakers with Dolby Digital 5.1 encoded sources.
■ Highly Rigid Chassis and Hybrid Loader Mechanism
The DVD-2800 incorporates a center mechanism mount that is struc-
turally very stable, and the mechanism's cover ensures that vibration
from the drive does not influence signal circuitry. The DVD-2800's
rigid chassis is constructed of a 15-mm thick front panel, a 1.6-mm
thick drive mechanism, and a 1-mm thick top cover, 1.2-mm thick
main chassis to thoroughly suppress internal and external vibration
and preserve signal integrity. The disc loader features a special hybrid
construction of molded plastic and metal that further absorbs vibration
for completely stable disc playback.
■ Other Versatile Features
• Multi-Angle Function (*3)
• Multi-Sound Function (*3)
• Multi-Subtitle (*3)
• Playback Memory Function
• Energy-Saving During Standby
• Auto Power OFF
DENON ELECTRONICS NIPPON COLUMBIA CO., LTD.
DIVISION OF DENON CORPORATION (USA) 14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011, JAPAN
19 CHAPIN ROAD, P.O. BOX 867, PINE BROOK, NJ 07058-9777 USA
TEL: 973-396-0810
www.del.denon.com
DENON CANADA INC.
17 DENISON STREET, MARKHAM ONTARIO, CANADA L3R 1B5
TEL: 905-475-4085
www.denon.ca
12540101 A Printed in Japan
L
R
Y
P B /C B
P R /C R
OPTICAL COAXIAL
VIDEO
OUT
AC IN
COMPONENT
VIDEOOUT
S-VIDEO
OUT
DIGITAL OUT
(PCM/BITSTREAM) AUDIO
OUT
®
*1 Discs that have been poorly finalized following recording may be only partially
playable or not playable at all.
*2 For discs recorded in Dolby Digital only.
*3 The DVD software needs to have this feature.
