SeaLand
®
MACERATOR TOiLET
OwnER’S MAnuAL
SeaLand
®
8800 Series All-Ceramic Toilets
Dometic Sanitation Corporation
328 State Rt. 226, P.O. Box 38, Big Prairie, OH 446 USA
SeaLand Product Hotline -800-32-9886 (8-5 ET)
8812 8818 8819
• Virtually silent flushing
• Three automatic flush cycle options:
- Normal (.82 gal., 3.1 L)
- Low (.42 gal., .6 L)
- Empty
• Powerful turbine macerator is virtually
clog-free; low electrical power draw
• Integral trapway (8818, 8819) pre-
vents potential odor and noise from
entering living space
• Plumbs to pressurized fresh water
system (2.5 gpm/9.5 lpm flow rate) or
raw water system with remote pump
• Optional shut-down feature prevents
overfilling of holding tank
MASTERFLuSh™ TEChnOLOgy FEATuRES
water
Supply
Water valve
Thread size 1/2 inch, 14 TPI
Flow rate at toilet 2.5 GPM/9.5 LPM
Raw water
pump
Hose ID 1/2 inch/13 mm
Raw water filters – 2 Coarse, Fine (00)
Discharge
Piping
Hose ID
Standard 1.5 inch/38 mm
with opt. adapter 1 inch/25 mm
Hose runs
Max. horizontal run 98 ft./30 m
Max. vertical run 9.8 ft./3 m
Electrical
System
Amp draw
(avg.)
12 volts DC 10-13 amps
24 volts DC 5-7 amps
Circuit breaker
12 volts DC 15 amps*
24 volts DC 10 amps*
inSTALLATiOn SPECiFiCATiOnS
* at 3.28 ft. (1 m) of pump discharge head
