Dukane DVP303A - Manual (Page 19)

Upper Lamp 2.7 Proceed with your setting or stop doing so:
2.7.1 If you have selected Save in Step 2.6, a "Save complete"
messages appears for three seconds. Then the screen to the one as
shown in 2.2. You may select
or press Menu on the remote
control to return to Layer 1; or, select to configure another lamp.
2.7.2 If you have selected Discard in Step 2.6, a "Discard your settings"
message appears. Then the screen returns to the one as shown in
Step 2.2.
2.8 Operation:
2.8.1 If you have your SPS settings ready, you may change the SPS-Off to
the one you want after the presenter has been switched on. In such a
way, the Lamp parameters may be loaded for service.
2.8.2 SPS Off:If you turn off the SPS mechanism, the set of Lamp
parameters at your last presentation will be used.
2.9 Notice:
2.9.1 When the SPS Setting 3 is selected on the menu, you can still adjust
the brightness and WB to meet the varied surrounding condition.
However, your modification will not be saved; that is, the values you
have specified in your SPS selection will be loaded the next time the
presenter is switched on.
2.9.2 The Default setting is the SPS setting by factory default.
5-8 Storage after Use
1. Fold the arm and the camera head until they touch the stage.
2. Turn the camera until it is parallel with the stage.
3. Turn the upper lamps toward the supporting arms.
4. Insert the remote control into the slot on the right of the Digital Presenter.
5. Fold them to both sides of the Digital Presenter until they lock in both sides.
Figure: 5–3
17
