Routing Cables thru Passage from
Bottom for Gen 7E base
Start to route cables thru passage from bottom according to the following
steps.
1. Release the indicated base stand back cover
and base cover.
2. Release the compression lock of base stand
cover at both sides.
3. Pass all cables through the indicated cable
exit then cable passage for external
connection.
4. Close the base stand back cover and base
cover.
4
