KEY M36(B,H) M42(B,H)
NO. VM36(B,H) VM42(B,H) DESCRIPTION QTY.
1 14574 106543-01 Limit Switch 1
2 ** ** Insulation Pan 1
3 ** ** Fireplace Top Assembly 1
4 ** ** Fireplace Surround 1
5 106642-01 106642-01 Air Rod Retainer 1
6 106643-01 106643-01 Damper Rod Retainer 1
7 106651-01 107805-01 Panel Closure 2
8 ** ** Firebox Bottom 1
9 ** ** Firebox Surround 1
10 106657-02 107811-02 Air Separator 1
11 11408 11408 Bushing 2
12 106658-02 107812-02 Left Refractory, Std. Brick
(M36B/M42B)
1
108164-02 108169-02 Left Refractory, Herringbone
(M36H/M42H)
1
106658-01 107812-01 Left Refractory, Std. Brick
(VM36B/VM42B)
1
108164-01 108169-01 Left Refractory, Herringbone
(VM36H/VM42H)
1
13 106659-02 107814-02 Right Refractory, Std. Brick
(M36B/M42B)
1
108165-02 108170-02 Right Refractory, Herringbone
(M36H/M42H)
1
106659-01 107814-01 Right Refractory, Std. Brick
(VM36B/VM42B)
1
108165-01 108170-01 Right Refractory, Herringbone
(VM36H/VM42H)
1
14 106660-02 107816-02 Rear Refractory, Std. Brick
(M36B/M42B)
1
108166-02 108171-02 Rear Refractory, Herringbone
(M36H/M42H)
1
106660-01 107816-01 Rear Refractory, Std. Brick
(VM36B/VM42B)
1
108166-01 108171-01 Rear Refractory, Herringbone
(VM36H/VM42H)
1
15 106661-02 107818-02 Bottom Rear Refractory, Std.
Brick (M36/M42, M36B/M42B)
1
108167-02 108172-02 Bottom Rear Refractory,
Herringbone (M36H/M42H)
1
106661-01 107818-01 Bottom Rear Refractory,
Std. Brick (VM36/VM42,
VM36B/VM42B)
1
108167-01 108172-01 Bottom Rear Refractory,
Herringbone (VM36H/VM42H)
1
16 106662-02 107820-02 Bottom Front Refractory,
Std. Brick (M36/M42,
M36B/M42B)
1
108168-02 108173-02 Bottom Front Refractory,
Herringbone (M36H/M42H)
1
106662-01 107820-01 Bottom Front Refractory,
Std. Brick (VM36/VM42,
VM36B/VM42B)
1
108168-01 108173-01 Bottom Front Refractory,
Herringbone (VM36H/VM42H)
1
17 ** ** Firebox Support Leg 2
PARTS LIST This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 20 of this manual.
KEY M36(B,H) M42(B,H)
NO. VM36(B,H) VM42(B,H) DESCRIPTION QTY.
PARTS LIST
M36(B,H), M42(B,H), VM42(B,H) and VM42(B,H) Models
18 106687-01 106887-02 Damper Can Collar 1
19 106691-01 107839-01 Screen Rod 2
20 ** ** Firebox Top Assembly 1
21 106699-01 106699-01 Transition 6" B-Vent Collar 1
22 106703-01 106703-01 Air Kit Door Assembly 1
23 ** ** Firebox Face 1
24 106948-02 107823-02 Smoke Deflector 1
25 ** ** Fireplace Top Insulation 1
26 107796-01 107796-02 Grate Assembly 1
27 107742-01 107742-02 Burner Pan 1
28 107795-01 107831-01 Burner Tube 1
29 107748-01 107748-01 Burner Bracket 1
30 107985-01 107985-02 Pilot Shield 1
31 901681-01 901681-01 Burner Clamp 1
32 11209 11209 Nut, #10-24 1
33 11147 11147 Screw, #10-24x1/2 1
34 901066-01 901066-01 Brass Air Mixer (NG) 1
901066-02 901066-02 Brass Air Mixer (LP) 1
35 901064-03 901064-08 Orifice (NG) 1
901065-13 901065-08 Orifice (LP) 1
36 108084-01 108084-01 Pilot - Natural Gas 1
37 108085-01 108085-01 Pilot Orifice (LP) 1
38 11102 11102 Screw, #8-32x3/8 2
39 14512 14512 Gas Control Valve (NG) 1
14513 14513 Gas Control Valve (LP) 1
40 107741-01 107741-01 Valve Bracket 1
41 14261 14261 Piezo Ignitor 1
42 111288-02 111288-02 Manual Valve with Flex Hose 1
43 108769-01 108769-02 Extension Deflector 2
44 108005-01 108005-01 Wire Harness 1
45 108005-02 108005-02 Wire Harness 1
46 11418 11418 Push-On Nut 2
47 12105 107840-01 Screen 2
48 14123 14123 Strain Relief 1
49 14153 14153 Micro Switch 1
50 ** ** Collar Insulation 1
51 20023 20488 Starter Collar 1
52 20027 20027 Brick Liner Retainer 2
53 20042 20042 Air Kit Cover 1
54 20088 20088 Door Stop 1
55 20089 20089 Pivot Clip 2
56 20090 20090 Spring Clip 2
57 20280 20280 Top Spacer 4
58 ** ** Gas Knockout Cover 4
59 ** ** Gas Conduit 1
60 ** — Gas Conduit 1
61 22912 22924 Draft Diverter 1
62 24353 24353 Box Assembly 1
63 11165 11165 Screw, #10x5/8 Mod. Tr. Blk. Ox 2
PARTS AVAILABLE NOT SHOWN
901155-01 901155-01 Vermiculite Bag 1
901156-01 901156-01 Pan Material 1
901157-01 901157-01 Lava Rock 1
22180 22180 Wall Switch Kit 1
** Not a field replaceable part.
