SP600
DA
TA SHEET SP600 Series of AC
Drives from 0.5 to 200
Horsepower
A full-featured industrial AC drive
suitable for wall, machine, flange, and
washdown mounted installations
The SP600 provides the benefits of
more expensive full-featured drives in a
compact, versatile, and cost effective
design. Multiple enclosure/packaging
options along with a drive mounted
graphical keypad and embedded
braking circuitry make this drive very
versatile. The wide range of network
options available for this product will allow
you to maximize data acquisition, speed
control and application flexibility.
Features/Specifications
• Control Modes
- Volts/Hertz
- Sensorless Vector Control
Each method can operate either a single or
multi-motor application from one SP600. SVC
is limited to mechanically coupled identical
motors.
• Input Voltages/Power Ratings
- 200, 208, 240 (0.5 to 10 HP)
- 380, 400, 415, 480 (0.5 to 200 HP)
- 575 (0.5 to 150 HP) 1
• Switching Frequency
- Full HP rating at 50°C for (45° for 50 HP;
40° for 200 HP):
• 4 kHz Frames A - D
• 4 kHz Frames 2 -5
• 4 kHz Frame 6 (2 KHz for 200 HP)
- Derating may apply for higher switching
frequencies
• Zero-stacking (side by side) panel mounting
possible for all frames.
1 575 VAC models are UL and cUL only
• Terminal Block Control
- 6 configurable digital inputs
- Up to 8 pre-set speeds
- Start/Stop, Forward/Reverse,Auto/Manual,
Jog, Preset Speed, Function Loss, ProcessPI
Control, etc.
- 2 Analog inputs
- 1 Analog output
- 2 Relay outputs, form C contacts.
• Drive Serial Interface
- PC configuration and monitoring of a single
drive or multiple drives when using V*S Utilities
Software.
• Overload Protecting
- Intelligent Thermal Management (ITM ™ ) system
can reduce carrier frequency or trip the drive in
overtemp conditions.
- UL and NEC approved electronic motor
overload protection.
• Enclosures/Mounting
- Wall or machine mount NEMA 1 (IP20)
- Flange mount NEMA 1 (IP20)
- See RAPS-958-2 for NEMA 4x/12
• Internal Braking transistor as standard (optional
Frames 4, 5, and 6) requires optional drive
mounted or externally mounted braking resistor
- Drive mounted resistor available for Frames A,
B, C, D, and 2
