EElleeccttrriiccaall C Coonnnneeccttiioonnss— —G Geenneerraall
The following diagram shows the common connections for this system.
WIRING SYSTEM:
YELLOW WIRE -- BATTERY (+)
RED WIRE -- ACC
BLACK WIRE -- GROUND
BLA
CK
YELLOW FU
SE
BLA
CK
RED
V-IN2 V-IN1
VIDEO-1
INPUT
VIDEO-2
INPUT
BLA
CK
8 8
