TECHNICAL SPECIFICATIONS
HT-1600
HT-2000
Combustion Type:
Wood Wood
Recommended Surface
900 à 1 600 ft
2
1 000 à 2 000 ft
2
(84 à 149 m
2
)
(93 à 186 m
2
)
Heating Capacity :
E.P.A :
40 000 BTU/h
(11,7 kW)
60 200 BTU/h
(17,6 kW)
Real
:
70 000 BTU/h
(20,5 kW)
95 000 BTU/h
(27,8 kW)
Efficiency :
71,3% 72,2%
Average Emission:
3,3 g/h
3,8 g/h
Colour :
Metallic Black
Metallic Black
Flue Pipe Diameter :
6’’ (152 mm)
6’’ (152 mm)
Chimney type :
2 100°F (650 °C)
2 100°F (650 °C)
Minimum Chimney Height :
12’ (3,66 m)
12’ (3,66 m)
Maximum Log Length :
18’’ (457 mm)
19’’ (483 mm)
Dimensions
Overall:
On Pedestal Model :
W x D x H
25 1/8 x 26 ½ x 32 5/8‘’
(638 x 673 x 828mm)
W x D x H
28 3/8 x 29 ½ x 34 3/8
(721 x 749 x 873mm)
Combustion Chamber :
Width x Depth :
Volume
:
18 ¼ x 15 ¼’’
(464 x 387 mm)
2,5 pi
3
(0,07 m
3
)
22 ½ x 18’’
(572 x 457 mm)
3,4 pi
3
(0,09 m
3
)
Door Opening :
Width x Height :
17 ¾ x 9 1/8'’
(425 x 222 mm)
17 3/4 x 9 1/8
(450 x 234 mm)
Pyroceram Glass Door :
Width x Height :
16 ¼ x 9 ½’’
(432 x 267 mm)
16 1/4 x 9 1/2
(413 x 241 mm)
Mass:
420 lbs (190 Kg)
560 lbs (254 Kg)
OPTIONS
Blower 75 CFM (2,83 m
3
/min) with
variable speed control
Yes
Yes
Thermodisc 100-120
o
F (37-49
0
C). Yes
Yes
