246-xxx Environmental Qualification Form
Rev: 1.00 Jun 17, 2008 Page 2 of 2
ENG-FORM: 521-0102.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
Conditions Section Description of Conducted Tests
Power input 16.0 Categories B and Z
• Emergency operating voltage was tested
Voltage spike 17.0 Category A
Audio frequency conducted
susceptibility 18.0 Category A
Induced signal susceptibility 19.0 Category A
Radio frequency susceptibility 20.0
Change No. 3
Category T
Emission of radio frequency
energy 21.0 Category Z.
Lightning induced transient
susceptibility 22.0
Change No. 2
Category XXC2
Lightning direct effect 23.0 Category X, no test required
Icing 24.0 Category X, no test required
REMARKS
:
- Tests of DO-160C, Sections 6.0, 7.0 and 8.0 were conducted at Northern Airborne
Technology Ltd. (NAT) in Kelowna, BC on Model 246.
-
Tests of DO-160C, Sections 16.0 and 18.0 were conducted at dB Systems, Inc. in
Redmond, WA on Model 246.
- Tests of DO-160C, Sections 4.0 (paragraphs 4.5.1, 4.5.2, & 4.5.3) and 5.0 were
conducted at dB Systems, Inc. in Redmond, WA on Model 245.
- Tests of DO-160C, Sections 4.0 (paragraphs 4.6.1, 4.6.2, 4.6.3), 15.0, 17.0, 19.0,
20.0, 21.0, and 22.0 were conducted at Allied Signal Aerospace, Inc. in Redmond,
WA, on Model 245.
-
Model 246-[ ] meets the requirements of RTCA DO-160C sections 4.0, 5.0, 15.0,
17.0, 19.0, 20.0, 21.0, and 22.0 by similarity to Model 245-[ ].
End of Environmental Qualification Form
