AA12S-600 Compact Stereo Audio Controller
SM84 Installation and Operation Manual
Section 2 Rev: 1.02 Issue 1 Page 2-6
ENG-FORM: 805-0121.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
2.6 Accessories Required But Not Supplied
Installation kit p/n D44P44SL-IKC (crimp) is required to complete the installation. The kit consists of the
D44SL-IKC and the D44PL-IKC.
D44SL-IKC consists of
Quantity Description NAT Part No.
1 D-min 44 Socket Housing 20-20-044
44 Mini D Crimp Socket 20-26-703
1 Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 pin Connector Hood 20-29-026
D44PL-IKC consists of
Quantity Description NAT Part No.
1 D-min 44 Socket Housing 20-20-044
44 Mini D Crimp Pin 20-26-704
1 Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 pin Connector Hood 20-29-026
* - Not required for the AA12S-6xx
2.7 Installation Drawings
DOCUMENT REV. DESCRIPTION TYPE
AA12S-600
AA12S\600\403-0 1.00 Compact Stereo Audio Controller Interconnect (3 sheets)
AA12S\600\405-0 1.00 Compact Stereo Audio Controller Connector Map
AA12S\600\922-0 1.20 Compact Stereo Audio Controller Mechanical Installation
Section 2 ends following the above documents
