DA80 Series DigiVOX™ Digital Intercom Manual SM57 Rev. 4.10
1.4.2
Physical Specifications
Dimensions: (Same size as the original AA80)
Height 1.35” (34.3 mm) max
Depth 5.62” (142.7 mm) max not including connector
Width 2.65” (67.3 mm) max
Weight 0.6 lb (0.272 kg) max
Faceplate Lexan label with vertical or horizontal legends.
Pressure sensitive adhesive backing attached
to a black anodized plate
Mounting Three black 6-32 brass screws that sandwich
the dash panel between the faceplate and
chassis. Aircraft panel thickness 0.050" to
0.125". The DA80 is mount-compatible with
the AA80-001
Material/Finish Brushed aluminum with chromate conversion
Connectors
One 25 pin male (DB25P) D-min connector
with Jackposts
1.4.3
Environmental Specifications
Temperature:
Operating -20 ° C to +55° C
Survival -55 ° C to +85° C
Altitude 50,000
ft
Humidity 95%
Shock:
Operational 6 g
Crash Safety 15 g
Qualification:
DA80-001: DO-160C Env. Cat. A1/D1-XAB[(SBM)(UF)]XXXXXXZBABAXMXXXX
DA80-010: DO-160D Env. Cat. A1/D1-BAB[(SBM)(UF)]XXXXXXZBABA[UUX]LXXXX
