AA36-ECF Tie Line Adapter Manual SM42 Rev. 4.00
Output Signal
ICS output:
Rated Level 500 mVrms into 5 k Ω
Freq. response <3 dB from 350 Hz to 6000 Hz
Distortion <10% @ rated output
Noise Level >60 dB down from rated output (without signal)
Isolation from ICS Input >35 dB
Adjust Trimpot 40 dB of range
Bi-directional Signals
NAT ICS Tie Line:
Signal Level 340 mVrms
Input impedance 1800 Ω ± 10%
Output Impedance 600 Ω
Freq. response <3 dB from 350 Hz to 6000 Hz
Distortion <10 % @ rated output.
1.4.2 Physical
Specifications
Height 1.25" (31.75 mm)
Depth 2.48" (62.99 mm) not including connector
Width 4.50" (114.30 mm) including flanges
3.50" (88.90 mm) excluding flanges
Weight 0.41 lbs (186 g)
Mounting Remote bulkhead mount: 4 x 10-32 screws.
Material/Finish Aluminum chassis and cover with chromate
conversion finish
Connectors 25-pin filtered male D-sub connector with jackposts
1.4.3 Environmental Specifications
Temperatures:
Operating -20 ° C to +55 ° C
Survival -55 ° C to +85 ° C
Altitude 35,000 ft.
Humidity 95%
Shock DO-160C Cat. M/N
Qualification:DO-160D Env. Cat. A1D1-XXB[(SBM)(UF)]XXXXXXXXXXX[UUX]MXXXX
End of section 1.0
Page 1-2 Dec 5, 2003
